Control of a DC motor – MOT

Model No. MOT

This laboratory is designed for the study of Control of a DC motor to allow the student a practical training, based on the performance of guided experiments.
Industrial type components must be educationally adapted by using a modular panel system to permit the step by step assembling from the simplest circuit to the most complex system.
This trainer has a modular structure and it consists of didactic panels installed on a vertical frame.
It is supplied with a theoretical and practical manual.
The modularity of this didactic system can give the students a direct and immediate approach to the topics, offering the opportunity to study various subjects.

performing several experiments as following:
– P, PI and PID controls of the speed of a DC motor using the CHR method
– Control of a DC generator
For more details download catalogue from here
