Programmable Logic

Model No. DL 2205PRL

This Board Allows The Study Of Ram Memories And Circuits Using Rams For Storing Logic Information And For Data Transfer To A Bus.

The Board Is Composed Of:
– 4 + 4 Buffers With Three-State Output
– 8 Bit Latch Register (Type D)
– 4 To 10 Line Decoder
– Ram 1024 X 4
– Hexadecimal Keypad
– Coder For Hexadecimal Keypad
– 8-Bit Digital-To-Analogue Converter
– 8-Bit Analogue-To-Digital Converter
– Multiturn Potentiometer For Generating Voltages Between 0 And 10V Power Supply: 5Vdcb

For more details download catalogue from here
