Hct – Ecl – Cmos

Model No. DL 2203SFL

This Board Allows The Study Of The Following Subjects:
– Electrical Characteristics Of The Integrated Circuits Of The Various Logic Families: Ecl, Cmos, Hct
– Laws And Principles For The Assembling Of Interface Circuits Among The Families
– Logic Gates
– Multiplexed Counters
– Programmable Shift Registers
– Bidirectional Transmission Gates
– Level Translators
– The Board Is Composed Of Three Sections:
– The Hct Section
– The Ecl Section
– The Cmos Section
– In Each Section Various Types Of Integrated Circuits Of T he Three Different Logic Families Are Assembled.
– Power Supply: +5Vdc, +12Vdc, 5.2Vdc
