Ball Graph And Closing Valve

Model No. MM01

The assembly, repair and maintenance MM01 kit allows to analyze the differences of a ball valve in front of a shut-off valve.

Thanks to the cutting of each system it is possible to study each one of the different components and their operation.

The material is supplied placed and protected in a box for transport along with the necessary tools for its use.

TECHNICAL CHARACTERISTICS OF THE BALL GRAPHIC
– Work pressure: PN 16
– Valve sphere type WAFER
– Assembly between flanges DIN PN-16
– Construction in Steel ASTM A 105
– Maximum work pressure 16Kg/cm²
– Work temperature -20ºC +180 ºC
– Kv= 130 (Kv:It is the number of cubic meters per hour that will pass through the valve generating a loss of charge of 1 bar)
For more details download catalogue from here
